Side Tilt Carriages - Rated by the blade carriage lifting capacity, there are four sizings of hook type fork carriages. The hook type blade carriages have been standardized.
Class I carriages are rated for loads as much as 2000 lbs. The carriage bar spacing utilized for Class I is 13 inches. Class II carriages are rated for cargo up to 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
The carriages for pin type tines can be different depending on the maker. Pin mounted blades may differ by the amount of offset between the tine eye and the blade. Carriage capacity will be determined by the carriage pin size and by the fork size.
